No other swaged heater is compacted to the extent of the hd offering efficient operation and long life for applications requiring high watt density capabilities.

Swaged cartridge heater.

Product description swaged cartridge heater voltage 120 lead length 10 in diameter 1 2 in length 6 in 500 watts watt density 58w sq. Looking for tempco swaged cartridge heater lead length 12 in 240v ac watts 400 w 226w sq in diameter 3 8 in 4njv7. Swaged cartridge heaters the hd swaged construction is in an elite category of high density swaged cartridge heaters. The majority of applications do not require maximum watt in.

Capability 1400 degrees f sheath material 321 stainless steel precision sheath dia. There are many standard sizes available for immediate delivery with sheath lengths from 1 inch 25 mm all the way up to 24 inches 610 mm with diameters ranging from as small as 0 25 in 6 mm all the way up to 0 78 in 19 8 mm. Tolerance 0 002 in. These durable cartridge heaters are swaged for greater thermal conductitivity making them very efficient.

For easy installation the heaters are made slightly undersize relative to their nominal diameter. Swaged cartridge heaters wind nichrome wire around a precision ceramic core and the carefully position the resistance wire and ceramic core uniformly inside the the heater sheath. Swaged cartridge heaters hotrods the engineers at backer marathon have developed a swaged cartridge heater that exceeds the performance and durability of others in the industry. Pure magnesium oxide mgo powder is then vibrated in and the heater is swaged to a specific diameter.

Grainger s got your back. Swaged cartridge heaters cartridge heaters are most frequently used for heating metal parts by insertion into drilled holes.
